UHMW-PE
UHMW has a molecular weight of 3.5～8.0 million, is much more greater than other ordinary high density polyethylene, which has a molecular weight of only ten of thousands to several hundred thousands Dalton. This contributes to its superb physical and chemical properties.
特性
◎Thickness is from 1mm
◎Light weight（Density is 0.97）
◎Wear and abrasion resistance
◎Anti-static electricity・・・・・long life for expendable parts
◎Dimensional stability under heat is 97 degrees
◎Notch impact strength is non-destruction
物性比較表
ＤＥＳＣＲＩＰＴＩＯＮ ＵＮＩＴ METHOD UHMW-PE UHMW-PE
Density g/㎤ DIN　53479 0.94 0.97
Abrasion　Index ％ Sand　Slurry 100 100
Tensｉｌe　Strength N/㎟ DIN　53455 22 22
Breaking　Strength@23℃ N/㎟ DIN　53455 44 43
Elongation　ａｔ　break@23℃ ％ DIN　53455 ＞350 ＞350
Shore　hardness D　scale DIN　53505 64 64
Notch　Impact　Strength N/㎟ DIN　53453 not destroy not destroy
Ball　Indentation　hardness N/㎟ DIN　53456 38 40
Melting　Temperature ℃ Polarisation 137 139
Linear　expansion　factor@23℃ ℃/m/m DIN　52328 2.1×10⁻⁴ 2.1×10⁻⁴
Thermal　Conductivity@23℃ W/℃.m DIN　52612 0.42 0.42
Dimensional　Stability　under　heat ℃ DIN　53461 95 ‐
Volume　resisｔance Ohm.cm DIN　53482 ＞10¹⁵ ＞10⁶
Surface　resistance Ohm DIN　53482 ＞4×10¹³ ＞10⁷
Dielectric　strength Kv/mm DIN　53481 ＞45 ‐
各種材料の摩耗比較
material Comparison value
UHMW-PE 1
Carbon steel 6.8
Stainless steel（SUS604） 5.2
POM 15.2
MC Nylon 3.8
PTFE 6.2
Polyurethane 5.6
Oilon

Our products are made by direct polymerization of nylon resin during casting. It is a typical engineering plastic that has a higher degree of crystallization than ordinary nylon resin, and features excellent mechanical strength, heat resistance, and creep properties.

特性
Our products can be applied to moving parts such as sliding boards, gears and rollers for steel equipment, solid parking lot parts, food machines, paper manufacturing machines, construction machines and Tooling machine.
